TECHNICAL DATA SHEET
Model | HOOK-120ZP |
Material | Zinc Plated Steel |
Size | 11 x 120 mm (0.433 x 4.72 inch) |
Eye Diameter | 17 mm (0.670 inch) |
Jaw Opening | 15 mm (0. 590 inch) |
Working Load | 450 kg (990 lb) |
Min. Breaking Strength | 900 kg (1980 lb) (2 x Working Load) |
Net Weight (100 pieces) | 19.20 kg (42.24 lb) |
Heavy duty zinc plated multipurpose spring snap hook provides easy connection to chain, rope or wire cable.
A = 50mm. |
B = 17mm. |
C = 12mm. |
D = 10mm. |
L = 100mm. |
